Weasler PTO Shaft – EUCV Wide Angle

Introducing the Weasler PTO Shaft, designed for optimal performance and durability. This high-quality shaft features a robust HP rating of 36HP at 540RPM, making it an essential component for various agricultural applications. The shaft is part of the AW21/W2380 series, ensuring compatibility and reliability.

Product Specifications

• Brand: Weasler
• German Series: AW21/W2380
• HP Rating @ 540RPM: 36
• HP Rating Range @ 540RPM: Up to 54
• Implement End: 1 3/8” x 6 Spline Q.R.
• Kilowatt Power Rating @ 540RPM: 26
• Lz Length (mm): 860
• PTO Series: AW21/W2380
• Reference: 1850-7402-086
• Related Products: 2448, 39070, 50694, 50697, 51152, 53507, 59624, 59644, 6048, 6583, 6678, 72448, 115404, 115409, 115431, 115437, 115438, 115439, 115442, 115445
• Tariff Code: 8483908990
• Torque (Nm): 780
• Torque Range: 335 – 1240Nm
• Total Closed Length (mm): 1488
• Tractor End: 1 3/8” x 6 Spline 80 W.A.
• Tube Profile: Lemon
• Tube Reference: OvGA/1G
• Universal Joint Dimensions: 27 x 75 & 24 x 91mm

Compatibility Information

This PTO shaft is designed for universal application and is not associated with any specific make or model.

Manufacturer Information

This product does not correspond to any particular OEM part number, ensuring versatility across various machinery.

Product Supplier: Sparex

Product Type: PTO Shaft

Product SKU: SP-39044
