Telescopic Bar Hole Stabiliser – S.15820

This Sparex telescopic bar hole stabiliser is a versatile and durable component designed for various agricultural applications. It features a robust construction with a minimum length of 365mm and a maximum length of 525mm, providing flexibility for different setups.

Key Features:

• Brand: Sparex
• Minimum Length: 365mm (14 3/8 inches)
• Maximum Length: 525mm (20 43/64 inches)
• Ball Size: 3/4 inch (19mm)
• Ball Width: 1 47/64 inch (44mm)
• End Fittings A: Ball 19mm
• End Fittings B: Thread 19mm
• Inner Bar: S.15477, A: 19mm, B: 44mm
• Pin Length: 42mm
• Pin Diameter: 3/4 inch (19mm)
• Thread Size: 1 1/8 inch
• Thread Type: UNC
• Tube Length: 260mm

Suitable For:

• Leyland – VARIOUS
• Marshall – VARIOUS
• Nuffield – VARIOUS

Additional Information:

• Related Products: 12798, 15477, 15478, 15600, 15629, 39, 73
• Tariff Code: 7303009090
• OEM Part Number: This product is not associated with any particular OEM part number.

This Sparex telescopic bar hole stabiliser is a reliable and high-quality replacement part for various agricultural machinery. Its adjustable length and robust construction make it a valuable addition to your equipment.
