Telescopic Bar Hole Stabiliser – S.15618

This Sparex telescopic bar hole stabiliser is a high-quality replacement part for a variety of Massey Ferguson tractors. It features a minimum length of 465mm and a maximum length of 730mm, making it suitable for a range of applications.

Product Specifications

• Alternative to: 15615
• Ball Size (ins): 3/4
• Ball Size (mm): 19
• Ball Width (ins): 1 47/64
• Ball Width (mm): 44
• Brand: Sparex
• End Fittings A: Ball 19mm
• End Fittings B: Thread 19mm
• Inner Bar: S.15477, A: 19mm, B: 44mm
• Maximum Length (ins): 28 3/4
• Maximum Length (mm): 730
• Minimum Length (ins): 18 5/16
• Minimum Length (mm): 465
• Pin Length (mm): 42
• Pin (ins): 3/4
• Pin (mm): 19
• Related products: 15476, 15477, 15478, 15600, 16496, 343, 39, 73
• Tariff Code: 7303009090
• Thread size: 1 1/8
• Thread type: UNC
• Tube Length (mm): 372

Suitable For

This telescopic bar hole stabiliser is suitable for the following Massey Ferguson tractors:

• 265
• 275
• 290
• 375E BRAZILIAN
• 390E BRAZILIAN
• 565
• 575
• 590
• 675
• 690

Manufacture Information

This product is not associated with any particular OEM part number.
