Introducing the Stauff Quick Release Hydraulic Coupling, designed for efficiency and reliability in hydraulic systems. This coupling features a Male 1/2” Body and a M22 x 1.50 Metric Male Bulkhead connection, making it an essential component for various applications.

Product Specifications

• Body Size: 1/2 inch
• Brand: Stauff
• Length (C): 76 mm
• Coupler Type: Standard Coupling with Poppet Valve
• Thread Size (E): M22 x 1.50
• Flow Rate: 100 LPM
• Height (H): 20.5 mm
• ISO Rating: ISO A
• Material: Carbon Steel
• Maximum Working Pressure: 250 bar
• Nose Diameter: 20.5 mm
• Reference: HP10-2-N1522
• Series: BG3
• Tariff Code: 7307119000
• Thread Type: Metric Male Bulkhead
• Tube Series: 15L

Compatibility Information

This product is not associated with any particular make or model, ensuring versatility across various hydraulic systems.

Manufacturer Information

Parker Hannifin
Part Number: 4V14E6X5-B

Enhance your hydraulic system’s performance with the Stauff Quick Release Hydraulic Coupling, a reliable choice for professionals seeking quality and durability.
