Creating a main and secondary beam connection from wood to wood

Main and secondary beam connection wood to wood with PITZL HVP 88010.0000 according to ETA-15/0187. Der Connection to secondary beam with 6 screws Heco Topix with a diameter of 4,5 mm and a length of 50 / 60 / 80 mm. Connection to main beam with 6 screws Heco Topix with a diameter of 4,5 mm and a length of 50 / 60 / 80 mm. A transverse tension lock is / is not to be provided in the area of the main / secondary beam. The main beam is / is not torsional fixed or sufficiently held. The serviceability has to be proven by the stiffness characteristics. A fire resistance time of 60 minutes is to be solved by appropriate design measures.

PURPOSE

Timber Structure Engineering

Main and Secondary Beam Connection

Wood to Wood Solutions

SUITABILITY

Cross Laminated Timber CLT

Glue Laminated Timber GLT

Solid Timber

SUMMARY

Item No. 88010.0000

Dimensions W x H x D (mm) 25 x 100 x 12

Number of Screws 12

Screw Size 4.5 x 50 – 80

Main Beam Min. Wood Dimensions 60 x 110

Secondary Beam Min. Wood Dimensions 45 x 110

Packaged Unit Quantity 20
